Submersible slurry pump

产品规格：Submersible slurry pump
订购电话：166-0318-1010
发布时间：2019-06-25 18:13:28
产品说明：
The submersible slurry pump is developed by screening and improving to overcome its existing deficiencies. It has been comprehensively optimized and innovatively designed in aspects such as the hydraulic model, sealing technology, mechanical structure, an

产品描述

The submersible slurry pump is developed by screening and improving to overcome its existing deficiencies. It has been comprehensively optimized and innovatively designed in aspects such as the hydraulic model, sealing technology, mechanical structure, and protection control. This product has a simple structure, is easy to install, is safe and reliable to use, and has a long service life. The pump can be submerged underwater without the need to build complex ground pump houses and fixing devices, and there is no noise or vibration, making the site tidier.

Features and Applications
The ZJQ type submersible slurry pump integrates functions of stirring, sand suction, and sand blowing. The main applications of this type of pump are river dredging, sand pumping for farmland reclamation, and sedimentation tank treatment.
Compared with ordinary slurry pumps and slag slurry pumps, this series of products has the following features:
It is not limited by the suction head, has high slag suction efficiency, and can carry out dredging more thoroughly.
All flow-through components are made of wear-resistant alloy, resulting in a long service life.
There is no need to be equipped with auxiliary stirring or spraying devices, which makes the operation simpler, with less investment and quick results.
The motor is submerged underwater, eliminating the need to build complex ground protection and fixing devices, making management more convenient.
The stirring impeller directly contacts the sedimentation surface, and the concentration can be controlled by adjusting the diving depth, so the concentration control is more flexible.
The equipment works directly underwater, with no noise or vibration, making the site tidier.
Model Significance
ZJQ 200 — 15 — 22
22 —— Matching motor power: 22kw
15 —— Rated head: 15m
200—— Rated flow rate: 200m³/h
ZJQ—— Model feature: Submersible slurry pump

The submersible slurry pump is suitable for conveying slurries containing abrasive particles such as sand, coal cinder, and tailings. It is mainly used in industries such as metallurgy, mining, power, chemical engineering, environmental protection, river dredging, sand pumping, and municipal engineering. The ZJQ submersible slurry pump is convenient to install and move, has high slag pumping efficiency, and can operate safely for a long time under harsh working conditions. It is an ideal product to replace traditional vertical submerged pumps and sewage submersible pumps.

3、Type Spectrum of Slurry Pumps

4、Structure diagram


ZJQ Performance Parameter Table：

【Friendly Reminder】: Due to the large number of product models and material classifications, please call for consultation to determine the price. If you need other supporting equipment such as electric motors and bases, please also call for consultation.。

序号 Serial No.	型号 Model	出水口径mm Outlet diameter (mm)	流量m³/h Flow m³/h	扬程m Lift m	电机功率KW Motor power kW	转速r/min Rotating speed r/min	间断通过*大粒度 mm Maximum granularity of interrupted passing mm	重量kg Weight kg
1	ZJQ30-10-3	65	30	10	3	1460	10	122
2	ZJQ25-12-3	65	25	12	3	1460	10	100
3	ZJQ30-16-4	65	30	16	4	1460	10	122
4	ZJQ25-20-4	65	25	20	4	1460	10	122
5	ZJQ45-15-5.5	80	45	15	5.5	1460	13	100
6	ZJQ50-10-5.5	80	50	10	5.5	1460	13	100
7	ZJQ25-30-7.5	80	25	30	7.5	1460	13	114
8	ZJQ30-30-7.5	80	30	30	7.5	1460	13	114
9	ZJQ32-20-7.5	80	32	20	7.5	1460	13	114
10	ZJQ45-15-7.5	80	40	15	7.5	1460	13	114
11	ZJQ100-10-7.5	100	100	10	7.5	1460	21	165
12	ZJQ25-40-11	80	25	40	11	1460	13	300
13	ZJQ40-25-11	80	40	25	11	1460	13	165
14	ZJQ50-21-11	80	50	21	11	1460	13	165
15	ZJQ50-26-11	80	50	26	11	1460	13	165
16	ZJQ70-20-11	80	70	20	11	1460	13	165
17	ZJQ100-18-11	100	100	18	11	1460	21	217
18	ZJQ100-16-11	100	100	16	11	1460	21	217
19	ZJQ25-40-15	80	25	40	15	1460	13	330
20	ZJQ50-26-15	80	50	26	15	1460	13	180
21	ZJQ50-28-15	80	50	28	15	1460	13	180
22	ZJQ60-30-15	100	60	30	15	1460	13	220
23	ZJQ70-24-15	80	70	24	15	1460	13	180
24	ZJQ75-25-15	100	75	25	15	1460	13	220
25	ZJQ100-18-15	100	100	18	15	1460	21	250
26	ZJQ150-15-15	100	150	15	15	1460	21	250
27	ZJQ150-18-18.5	150	150	18	18	980	32	550
28	ZJQ200-12-18.5	150	200	12	12	980	45	550
29	ZJQ100-25-22	150	100	25	25	980	32	580
30	ZJQ100-32-22	150	100	30	30	980	32	580
31	ZJQ150-22-22	150	150	22	22	980	32	580
32	ZJQ200-15-22	150	200	15	15	980	45	580
33	ZJQ60-46-30	150	60	46	46	980	21	700
34	ZJQ70-38-30	150	70	38	38	980	21	550
35	ZJQ75-40-30	150	75	40	40	980	21	550
36	ZJQ100-35-30	150	100	35	35	980	21	550
37	ZJQ108-30-30	150	108	30	30	980	21	550
38	ZJQ150-30-30	150	150	30	30	980	21	550
39	ZJQ150-35-30	150	150	35	35	980	21	550
40	ZJQ200-20-30	150	200	20	30	980	21	550
41	ZJQ240-20-30	150	240	20	30	980	21	550
42	ZJQ300-15-30	200	300	15	30	980	28	700
43	ZJQ100-50-37	150	100	50	37	980	21	918
44	ZJQ300-20-37	200	300	20	37	980	28	850
45	ZJQ400-15-37	200	400	15	37	980	28	850
46	ZJQ100-60-45	200	100	60	45	980	36	950
47	ZJQ150-35-45	150	150	35	45	980	36	1000
48	ZJQ200-30-45	150	200	30	45	980	36	1000
49	ZJQ500-15-45	250	500	15	45	980	46	1100
50	ZJQ150-45-55	150	150	45	55	980	21	1140
51	ZJQ250-35-55	150	250	35	55	980	36	1140
52	ZJQ600-15-55	250	600	15	55	980	46	1186
53	ZJQ200-45-75	150	200	45	75	980	21	1540
54	ZJQ350-35-75	200	350	35	75	980	28	1550
55	ZJQ400-25-75	200	400	25	75	980	25	1550
56	ZJQ500-20-75	200	500	20	75	980	25	1550
57	ZJQ200-50-75	150	200	50	75	980	14	1500
58	ZJQ200-60-90	150	200	60	90	980	14	1550
59	ZJQ400-40-90	200	400	40	90	980	28	1550
60	ZJQ500-25-90	200	500	25	90	980	25	1550
61	ZJQ400-50-110	200	400	50	110	980	28	1970
62	ZJQ500-54-110	200	500	54	110	980	28	1970
63	ZJQ600-30-110	200	600	30	110	980	28	1970
64	ZJQ780-26-110	300	780	26	110	980	50	1970
65	ZJQ1000-18-110	300	1000	18	110	980	50	1986
66	ZJQ400-60-132	200	4000	60	132	980	28	2000
67	ZJQ500-45-132	200	500	45	132	980	28	2000
68	ZJQ500-55-132	200	500	55	132	980	28	2000
69	ZJQ800-35-132	300	800	35	132	980	42	2000
70	ZJQ1000-22-132	300	1000	22	132	980	50	2000
71	ZJQ650-52-160	200	650	52	160	980	28	2650
72	ZJQ80-50-185	300	780	50	185	980	38	3330
73	ZJQ800-55-220	300	800	55	220	980	38	3400
74	ZJQ1250-35-220	350	1250	35	220	980	45	3400
75	ZJQ1750-30-250	350	1750	30	250	980	55	3500
76	ZJQ1500-35-250	350	1500	35	250	980	50	3500
77	ZJQ2000-35-315	400	2000	35	315	980	60	3700
78	ZJQ20-25-4(K)	65	20	25	4	1460	10	122
79	ZJQ45-15-5.5(K)	80	45	15	5.5	1460	13	140
80	ZJQ50-10-5.5(K)	80	50	10	5.5	1460	13	140
81	ZJQ25-30-7.5(K)	80	25	30	7.5	1460	13	150
82	ZJQ30-30-7.5(K)	80	30	30	7.5	1460	13	150
83	ZJQ32-20-7.5(K)	80	32	20	7.5	1460	13	150
84	ZJQ45-15-7.5(K)	80	45	15	7.5	1460	13	150
85	ZJQ100-10-7.5(K)	100	100	10	7.5	1460	21	165
86	ZJQ25-40-11(K)	80	25	40	11	1460	13	180
87	ZJQ40-25-11(K)	80	40	25	11	1460	13	180
88	ZJQ50-21-11(K)	80	50	21	11	1460	13	180
89	ZJQ50-26-11(K)	80	50	26	11	1460	13	180
90	ZJQ70-20-11(K)	80	70	20	11	1460	13	180
91	ZJQ100-18-11(K)	100	100	18	11	1460	21	217
92	ZJQ100-16-11(K)	100	100	16	11	1460	21	217
93	ZJQ25-40-15(K)	80	25	40	15	1460	13	230
94	ZJQ50-26-15(K)	80	50	26	15	1460	13	200
95	ZJQ50-28-15(K)	80	50	28	15	1460	13	200
96	ZJQ60-30-15(K)	100	60	30	15	1460	13	220
97	ZJQ70-24-15(K)	80	70	24	15	1460	13	220
98	ZJQ75-25-15(K)	100	75	25	15	1460	13	220
99	ZJQ100-18-15(K)	100	100	18	15	1460	13	220
100	ZJQ50-50-22(K)	65	50	50	22	1480	13	420
101	ZJQ100-30-22(K)	100	100	30	22	1480	13	420
102	ZJQ300-10-22	200	300	10	22	980	37	617
103	ZJQ200-15-22(k)	150	200	15	22	980	45	580
104	ZJQ160-30-37(K)	100	160	30	37	1460	21	740
105	ZJQ400-25-45(K)	150	400	25	45	1460	35	880
106	ZJQ160-38-45(K)	100	160	38	45	1460	21	880
107	ZJQ120-60-55(K)	80	120	60	55	1460	21	960
108	ZJQ250-35-55(K)	125	250	35	55	1460	25	960
109	ZJQ150-60-75	150	150	60	75	1460	32	1125
110	ZJQ250-40-75	150	250	45	75	1460	32	1125
111	ZJQ450-25-75	200	450	25	75	1460	28	1125
112	ZJQ200-50-75	150	200	50	75	1460	32	1125
113	ZJQ150-75-75	150	150	75	75	1460	32	1125
114	ZJQ460-35-90(K)	200	460	35	90	1460	40	1160
115	ZJQ100-110-90	150	100	110	90	1460	21	1160
116	ZJQ150-80-90	150	150	80	90	1460	21	1160
117	ZJQ160-70-90	150	160	70	90	1460	21	1160
118	ZJQ250-60-90	150	250	60	90	1460	21	1160
119	ZJQ300-45-90	150	300	45	90	1460	21	1160
120	ZJQ450-30-90	200	450	30	90	1460	28	1160
121	ZJQ450-45-110	200	450	45	110	1460	28	1450
122	ZJQ600-30-110	200	600	30	110	1460	28	1450
123	ZJQ150-120-132	200	150	120	132	1460	36	1500
124	ZJQ250-70-132	150	250	70	132	1460	36	1500
125	ZJQ300-65-132	150	300	65	132	1460	36	1500
126	ZJQ700-30-132	250	700	30	132	1460	46	1500
127	ZJQ200-90-132	150	200	90	132	1460	21	1500
128	ZJQ900-30-160	250	900	30	160	1460	46	1880
